Sony Tektronix VX4792 - Figure 2-24: Equation Using Abs; Figure 2-25: Equation Using Int

Functional Overview
VX4792 User Manual
2-25
+1.0
-1.0
Equation: range(0,100ms)<LF>abs(sin(2*pi*x))
1000 Points ; Clock 1e+07 Hz
Figure 2-24: Equation Using Abs
-1.0
+1.0
Equation: range(0,100ms)<LF>int(5*sin(2*pi*x))/5
1000 Points ; Clock 1e+07 Hz
Figure 2-25: Equation Using Int
