Table 3-13: Waveform Commands
Header Description
AUTOStep:DEFine(?) Send the auto step data associated with the specified channel to a file in the waveform generator
CURVe(?) Transmit a waveform between the external controller and the waveform generator
DATA? Query all current settings related to the waveform or marker data to be transferred
DATA:DESTination(?) Define the destination to which the waveform is to be transferred
DATA:ENCDG(?) Select the waveform data transfer format
DATA:SOURce(?) Designate the source from which waveform is transferred
EQUAtion:COMPile Compile the equation expression
EQUAtion:DEFine(?) Write the equation expression into a file
EQUAtion:WPOints(?) Write a specified number of waveform points
MARKer:DATA(?) Transmit marker data between the external controller and the waveform generator
MARKER<x>:AOFF Set all markers to off
MARKER<x>:POINt(?) Set the marker to the specified point
SEQUence:DEFine(?) Write a sequence to a file
SEQUence:EXPand Expand a sequence file into a single waveform file
WAVFrm? Transmit the waveform preamble and waveform from the waveform generator to the external controller
WFMPre? Query all the current preamble settings
WFMPre:BIT_NR(?) Specify the bits of precision per byte
WFMPre:BN_FMT(?) Specify the binary data format
WFMPre:BYT_NR(?) Specify the data field width for each binary data point
WFMPre:BYT_OR(?) Specify the byte order
WFMPre:CRVCHK(?) Specify the error check method
WFMPre:ENCDG(?) Set waveform data encoding
WFMPre:NR_PT(?) Set the number of waveform data points
WFMPre:PT_FMT(?) Define format of data
WFMPre:PT_OFF(?) Define the XĆaxis point offset value
WFMPre:WFID(?) Set comment and additional information
WFMPre:XINCR(?) Define the XĆaxis increment value
WFMPre:XUNIT(?) Define the XĆaxis data unit type
WFMPre:XZERO(?) Define the XĆaxis origin offset value
WFMPre:YMULT(?) Define the YĆaxis data multiplier value
WFMPre:YOFF(?) Define the YĆaxis offset value
WFMPre:YUNIT(?) Define the YĆaxis data unit type
WFMPre:YZERO(?) Define the YĆaxis origin offset value
