Sony Tektronix VX4792 - Figure 2-20: Equation Using Exp; Figure 2-21: Equation Using Log

Functional Overview
VX4792 User Manual
2-23
+1.0
-1.0
Equation: range(0,50ms)<LF>1-exp(-5*x)<LF>range(50ms,100ms)<LF>exp(-5*x)
1000 Points ; Clock 1e+07 Hz
Figure 2-20: Equation Using Exp
+1.0
-1.0
Equation: range(0,100ms)<LF>log(10*(x+0.1))
1000 Points ; Clock 1e+07 Hz
Figure 2-21: Equation Using Log
