Functional Overview
2-28
VX4792 User Manual
-1.0
+1.0
Equation: range(0,33ms)<LF>-0.5<LF>range(33ms,66ms)<LF>0.5<LF>
range(66ms,100ms)<LF>-0.5<LF>range(0,100ms)<LF>diff()
1000 Points ; Clock 1e+07 Hz
Figure 2-30: Waveform Before Calculating Differentiation
-1.0
+1.0
1000 Points ; Clock 1e+07 Hz
Figure 2-31: Waveform After Differentiation Using Diff
