INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 3 of 58
1296-M010-0_P
Space s.r.l.
ER232R - ER234R - ER236R - ER238R - ER238RFM - ER248R - ERP248R
20.3 Setting adhesive weight dimensions _ 49
21.0 WHEEL BALANCER CALIBRATION _ 50
21.1 “Zero chucking-table” setting without
anything ____________________________ 51
22.0 ERROR SIGNALS __________________ 52
23.0 ROUTINE MAINTENANCE _________ 53
24.0 TECHNICAL DATA _________________ 54
24.1 Dimensions __________________________ 55
25.0 STORING __________________________ 57
26.0 SCRAPPING _______________________ 57
27.0 REGISTRATION PLATE DATA _____ 57
28.0 FUNCTIONAL DIAGRAMS _________ 57
Table A - Electrical and pneumatic
connection diagram ____________ 58
29.0 LIST OF COMPONENTS
