INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
5
6
7
8
9
10
11
12
13
1296-M010-0_P
Space s.r.l.
ER232R - ER234R - ER236R - ER238R - ER238RFM - ER248R - ERP248R
KEY
1 – Weight holding bridge
2 – LCD display/control panel
3 – Distance caliper
4 – Threaded mandrel
5 – Protection guard (only for ER234R - ER238R - ER238RFM models)
6 – Pedal brake (only for ER238RFM models)
7 – Main switch
8 – Ring nut with hand-wheel (only for ER232R - ER236R model)
9 – Rapid ring nut (only for ER234R - ER238R - ER238RFM models)
10 – GAR301 automatic external data gauge(optional for ER236R - ER238R - ER238RFM)
11 – Pusher ring
12 – Grippers for weight fitting
13 – Cones
Fig. 1 - ER232R - ER234R - ER236R - ER238R - ER238RFM
