Sparsh Dual Streaming - Front Panel

- 8 -
Storage Capacity
1 or 2 SATA Interface (2TB/4TB)
Alarm
4 Inputs, 1 Output (NC, NO relay
Network
RJ-45 10/ 100 Base T Ethernet connector (PPPoE, DHCP, DDNS, Static IP),
UPnP and FTP
Network Function
IE Browser Live Monitor, Configuration, Download Video, Playback, and
Mobile Phone Surveillance
USB 2.0 Interface
Mouse/Potable Mobile HDD/Flash Drive/DVD Burner/Firmware Upgrade
Playback method
Normal Play, Fast Forward, Backward, Single Step
RS485/PTZ
1 x RS485
PTZ Protocol
PELCO-P , PELCO-D, Samsung, Panasonic, Philips etc.
Video Backup
AVI, MPEG4 or H.264 Raw for USB Flash Disk
Power
DC12V/3.3A or 5A(optional for 2 SATA)
Operating Temperature
O’C ~ +40-C
Dimension
315(W) x 224(D )x 52(H) mm
315(W) x 224 (D) x 52 (H) mm or
436(W) x 339(D) x 55(H)
Model
SP3278B-KW3278C (1XHDD)
SP3279B-KW3279C
(
2XHDD
)
KW3274B-KW3274C(1XHDD)
KW3275B-KW3275C
(
2XHDD
)
2.2 Panels and Remote Controller
Front Panel
Please take actual front panel as quasi-:
4CH DVR
1. CH1 ~ Ch4 /
Direct switch to single camera window or 4 camera windows
Start and Stop time setting of
playback or back up in schedule record(Chapter 4.5 Video Playback
), or 5.4.6 Motion/5.4.7 Privacy
Mask setting(Mosaic) setting, or 5.3.2 Record Schedule/5.6.4 Alarm Schedule setting
