Introduction
1 Specification sheet (optional)
Table 1: Packaging List of the HSA
1.6 EC10 Can-Ethernet-Adapter
1.6.1 Introduction
The EC10 is an external CAN-Bus adapter for the PC. It is connected to the PC via an
ethernet network. The PC's access to CAN-Bus controlled devices like the HSA is
provided by the EC10 and the communication between PC and EC10 is handled by
the standard TCP/IP network protocol.
Figure 1: Rear Side of the EC10
Figure 2: Front Side of the EC10
4 HSA3500 / HSA3500 plus Power Supply
