Introduction
off. If the self-test fails, the “PWR” LED will blink with a frequency of 2 Hertz and
the other LEDs will indicate the reason of failure. In this case the device will not be
operable and should be returned to SPECS for service.
If no LED flashes at all, the presence of the 24 Volt power supply should be checked.
Contact SPECS for furter advice.
1.6.3 Power Requirements
The EC10 needs a 24 Volt supply voltage. Usually this voltage is provided by the HSA
via the CAN-Bus cable. A 24 Volt supply voltage can be fed to the EC10 via the DC
socket labelled “24V” at the front side of the housing as well. The typical current
drain of the device is 48 mA.
1.6.4 Pin Setting of the CAN Bus Connector
The Pin setting of the CAN BUS connector is given in table 6, the naming is depicted
in figure 3.
CAN Bus Pin Name
1 +24V
2 CAN Low
3 0V
4 +24V
5 0V
6
7 CAN High
8
9
Table 3: Pin setting of the CAN Bus connector
6 HSA3500 / HSA3500 plus Power Supply
