HSA config files (*.hsa)
HardwareName = HSA3500 CCD with deflector # only for information
FileFormat = 5
ModeParts = "Lens Mode:Range" # standard mode name schema
}
Entry Type Description
HardwareType unsigned long,
mandatory
Used to validate that the configuration file
matches the actual HSA hardware
HardwareName string,
optional
A hardware describing text, for
information purposes only
FileFormat unsigned long,
mandatory
File format number, current value is 5
ModeParts string,
optional
Format: <part-1>:<part2->:...:<part-n>
describing of what parts a mode name is
composed of.
Default value is “Lens Mode:Range”
Table 16: Info section description
3.2.10.2 SplineList Section
This section contains a sequence of all spline definitions in the configuration file.
Each element of the sequence is a [Spline] subsection without a body.
An example for a [SplineList] section is:
[SplineList] GlobalSplines # list of all global defined splines
{
[Spline] HighMagnification_T2
[Spline] HighMagnification_T3
[Spline] HighMagnification_T4_T7
[Spline] HighMagnification_T8
[Spline] HighMagnification_T9
...
}
Section Type Description
Spline string, optional, no body Name of a spline definition
Table 17: SplineList section description
32 HSA3500 / HSA3500 plus Power Supply
