SPECS HSA3500 User Manual

Using the HSA
Physical
Meaning
PIN
(12-pin)
PIN
(30-pin)
HM MM LM LA
IHP 1 Analyzer-C3 -766.7 -766.7 -766.7 -766.7
T2 2 Lens-B4 -660.2 -751.7 -556.8 -708
T3 3 Lens-A3 -747.4 -456.9 58 -516
OHP 4 Analyzer-C7 -788 -788 -788 -788.0
T4 - T7 5 Lens-C5 -719.9 -757.9 -720.2 -759.4
T4 - T7 6 Lens-C5 -719.9 -757.9 -720.2 -759.4
T8 7 Lens-B8 -606.1 -679.6 -626.1 -559.4
T9 8 Lens-A7 -780 -780 -780 -536
GP 9 Analyzer-A9 -780 -780 -780 -780.0
IH 10 Analyzer-A5 -766.7 -766.7 -766.7 -766.7
OH 11 Analyzer-C9 -788 -788 -788 -788
Coil 12 Lens-C3 - - - -
Table 12: Voltages to Ground (Ekin = 800eV, Ep = 20 eV, WF=0), PHOIBOS 100/150 R6
or higher, for typical XPS applications
24 HSA3500 / HSA3500 plus Power Supply
