precision digital voltmeter; for the high voltage ranges measurements (1500V,
3500V) a high voltage probe (1000:1) should be used to avoid an excessively high cur-
rent load (-> voltage drop).
Mind the safety instructions given on page 8
Note the influence of the workfunction (the spectrometer voltage U0 is nominal
equal to
Ekin - Ep + workfunction
).
2.3.2.2 Fast Check of Voltage Ranges (energy scale).
Start a measurement in fixed energy mode or use the HSA3500 Juggler program (see
SpecsLab2 manual) to check the voltages at the ground plate (pin 9 of the analyzer
connector, figure 36, Schematics of the 12-pin analyzer feedthrough, page 71).
Range (V) Ek Ep PIN 9 Correct with analyzer
settings
40 0 0 0 offset 40V range
40 40 1 -39 gain 40V range
400 0 0 0 offset 400V range
400 400 10 -390 gain 400V range
Table 10:
Voltage (energy scale) check for 40V and 400V range
Range(V) Ek Ep PIN 9 Correct with analyzer
settings
1500 0 0 0 offset 1500V range
1500 1500 50 -1450 gain 1500V range
3500 0 0 0 offset 3500V range
3500 3500 100 -3400 gain 3500V range
Table 11: Voltage (energy scale) check for 1500V and 3500V range (with high voltage
probe 1000:1)
HSA3500 / HSA3500 plus Power Supply 19
