4.2.5 0x04 – 3.5kV Lens bipolar (HSA3500 plus module)
Channel ADC name Description DAC Output Pin
0 Mon U1 Relay Output 1 20
1 Mon U2 Relay Output 2 14
2 Uerr
3 Mon I0 Total current
4 Mon U0 Voltage Output 0 26
5 N / A N / A N / A
6 N / A N / A N / A
7 N / A N / A N / A
Table 33: HSA3500 plus 0x04 ADC mapping
Module voltage
range
Q3
Relay Out 2
Q2
Relay Out 1
Q1
Range 0
Q0
Range 1
Hex
value
-3500V to +3500V
1 1 0x03
1 1 1 0x07
1 1 1 0x0B
1 1 1 1 0x0F
-1500V to +1500V
1 0x01
1 1 0x05
1 1 0x09
1 1 1 0x0D
-600V to +600V
1 0x02
1 1 0x06
1 1 0x0A
1 1 1 0x0E
-150V to +150V
0x00
1 0x04
1 0x08
1 1 0x0C
Table 34: HSA3500 plus 0x04 Operation Modes
