4.2.6 0x14 – 3.5kV analyzer bipolar (HSA3500 plus module)
Channel ADC name Description DAC Output Pin
0 Mon U1 Voltage Output 1 20
1 Mon U0 Voltage Output 0 26
2 Uerr
3 Mon I Total current
4 Mon U2 Voltage Output 2 14
5 N / A N / A N / A
6 N / A N / A N / A
7 N / A N / A N / A
Table 35: HSA3500 plus 0x14 ADC mapping
Module voltage
range
Q3
Relay Out 2
Q2
Relay Out 1
Q1
Range 0
Q0
Range 1
Hex
value
-3500V to +3500V
1 1 0x03
1 1 1 0x07
1 1 1 0x0B
1 1 1 1 0x0F
-1500V to +100V
1 0x02
1 1 0x06
1 1 0x0A
1 1 1 0x0E
Table 36: HSA3500 plus 0x14 Operation Modes
