Entry Type Description
MappedToDacId string, optional Overrides the value of the
‘MappedToDacId’ entry in a global
[LogicalVoltageDef] section with the
same name for this HSA3500 mode
MinValue double, optional Overrides the value of the ‘MinValue’
entry in a global [LogicalVoltageDef]
section with the same name for this
HSA3500 mode
MaxValue double, optional Overrides the value of the ‘MaxValue’
entry in a global [LogicalVoltageDef]
section with the same name for this
HSA3500 mode
MinValuePP double, optional Overrides the value of the ‘MinValuePP’
entry in a global [LogicalVoltageDef]
section with the same name for this
HSA3500 mode
MaxValuePP double, optional Overrides the value of the ‘MaxValuePP’
entry in a global [LogicalVoltageDef]
section with the same name for this
HSA3500 mode
Step double, optional Override the value of the ‘Step’ entry in
a global [LogicalVoltageDef] section
with the same name for this HSA3500
mode
Table 23: LogicalVoltage subsection in a ModeDef section
Entry Type Description
Slot unsigned long,
optional
Number of the HSA3500 slot containing a
HSA35000 power supply module, which
should not generate any DAC voltage in
this mode. If there exists a “DacVoltage”
definition with a name matching the first
part of the “SlotHVOff” definition, their
slot number is taken over.
OperationMod
e
unsigned long,
optional
Operation mode of the unused HSA3500
power supply, necessary if the module
contain relays needed in this mode. If
there exist no “DacVoltage” definition
with a name matching the first part of the
“SlotHVOff” definition this entry is
mandatory.
Table 24: SlotHVOff subsection in a ModeDef section
HSA3500 / HSA3500 plus Power Supply 39
