HSA config files (*.hsa)
Entry Type Description
ShortName string,optional Short name for the HSA3500 mode for use
in the control software user interace.
MinRR double, optional Minimum value for the retardation ratio
(Ekin - WF)/Ep in this mode. Used to
determine which logical voltage settings
are vaild.
Default: -1.0, ignored for negative values
MaxRR double, optional Maximum value for the retardation ratio
(Ekin/Ep) in this mode. Used to determine
which logical voltage settings are valid.
Default: -1.0, ignored for negative values
Hidden optional If set, this mode is disabled by the control
software software until it is explicitly
enabled in the program options.
Default: false
LogicalVoltage optional, multiple Describe the values of a global defined
logical voltage are overridden in this
HSA3500 mode (for details see below).
SlotHVOff optional, multiple In some modes an existing HSA3500 power
supply is not used to generate any output
voltage, but its relays must be configured.
This is done by this sections. This is also the
only way to delete a DAC voltage
definition inherited by a parent [ModeDef]
section (for details see below).
DacVoltage optional, multiple Describe a DAC voltage generated by the
HSA3500 in this mode (for details see
below).
Table 22: ModeDef section context
38 HSA3500 / HSA3500 plus Power Supply
