Appendix

4.2.3 0xd1 – 3.5kV unipolar (HSA3500 module)

Channel ADC name Description DAC Output Pin

0 N / A N / A N / A

1 Mon U0 Voltage Output 0 26

2 Mon U1 Relay Output 1 20

3 Mon U2 Relay Output 2 14

4 N / A N / A N / A

5 N / A N / A N / A

6 Mon I Total current

7 N / A N / A N / A

Table 30: HSA3500 0xd1 ADC mapping

Voltage Range

Relay Out 2

Relay Out 1

Range

Hex

0V to +3500V

x 0x00

1 x 0x02

1 x 0x04

1 1 x 0x06

Table 31: HSA3500 0xd1 Operation Modes

56 HSA3500 / HSA3500 plus Power Supply
