Appendix
4.2.7 0x24 – 400V bipolar (HSA3500 plus module)
Channel ADC name Description DAC Output Pin
0 N / A N / A N / A
1 N / A N / A N / A
2 Mon U2 Voltage Output 2 14
3 Mon U1 Voltage Output 1 20
4 Mon U0 Voltage Output 0 26
5 Mon I0 Current Output 0 26
6 Mon I1 Current Output 1 20
7 Mon I2 Current Output 2 14
Table 37: HSA3500 plus 0x24 ADC mapping
DAC Module voltage
range
Q3
Range 10V
Q2
Range
DAC0
Q1
Range
DAC1
Q0
Range
DAC2
Hex
value
0
-400V to +400V 1 0x01
-100V to +20V 0x00
1
400V to +400V 1 0x02
-100V to +20V 0x00
2
400V to +400V 1 0x04
-100V to +20V 0x00
0, 1, 2 -10V to +10V 1 x x x 0x08
Table 38: HSA3500 plus 0x24 Operation Modes
Notice:
If you use the 10V range, the high voltage stage at the module is off (voltage ripple
is then very small). That means the range bits Q0, Q1, Q2 are don't care.
60 HSA3500 / HSA3500 plus Power Supply
