SPECS HSA3500 User Manual

4.3 Hardware type and backplane wiring
In order to be able to differentiate the various HSA, has SPECS defined a hardware
type and a backplane wiring.
Hardware
type
Backplane
wiring
Number
of
modules
Type
of HSA
Comments
1 A, B 9 HSA3500 Prototype
2 C 9 HSA3500
3 C 10 HSA3500
4 C 11 HSA3500
5 C 11 HSA3500
6 HSA3500 Internal only
7 D 9 HSA3500 Standard MCD (old)
8 D 10 HSA3500
9 D 10 HSA3500
10 D 11 HSA3500
11 E HSA3500
12 F 12 HSA3500
13 D 12 HSA3500
14 I 10 HSA3500 Standard MCD
15 I 11 HSA3500 Standard CCD
17 K 12 HSA3500 Standard CCD + Defl
18 O 12 HSA3500 Standard MCD + 2x400V
19 P 13 HSA3500 Standard CCD + Defl + Screen
20 I 11 HSA3500 Standard MCD + 1x400V
21 I 11 HSA3500 Standard MCD + Screen
22 I 7 HSA3500
23 R 13 HSA3500 Wide Angle
24 S 11 HSA3500
25 T 12 HSA3500
26 U 10 HSA3500 THEMIS
27 V 3 HSA3500 BIS
HSA3500 / HSA3500 plus Power Supply 63
