1.9 Modules
There are different modules within the HSA. All modules have an internal type num-
ber (Table 6 and Table 7). Every module has a serial number and production date
printed on the board.
Type Name
- Main CPU
0xf1 3.5kV bipolar
0xe1 400V bipolar
0xd1 3.5kV unipolar
0xb1 150mA unipolar
Table 6: HSA3500 modules
Type Name
- Main CPU with current module
150mA
0x04 3.5kV Lens bipolar
0x14 3.5kV Analyzer bipolar
0x24 400V bipolar
0x34 3.5kV unipolar
Table 7: HSA3500 plus modules
HSA3500 / HSA3500 plus Power Supply 11
