Note: HSA3500 and HSA3500 plus do not have the identical ADC channels and can also

not have same outputs at the connector. So please be careful and pay attention.

4.2.1 0xf1 – 3.5kV bipolar (HSA3500 module)

Channel ADC name Description DAC Output Pin

0 N / A N / A N / A

1 Mon U0 Voltage Output 0 26

2 Mon U1 Relay Output 1 20

3 Mon U2 Relay Output 2 14

4 N / A N / A N / A

5 N / A N / A N / A

6 Mon I Total current

7 N / A N / A N / A

Table 26: HSA3500 0xf1 ADC mapping

Voltage range

Relay Out 2

Relay Out 1

Range

Hex value

-3500V to +3500V

0x00

1 0x02

1 0x04

1 1 0x06

-1500V to +100V

1 0x01

1 1 0x03

1 1 0x05

1 1 1 0x07

Table 27: HSA3500 0xf1 Operation Modes

54 HSA3500 / HSA3500 plus Power Supply
