Operation
— 36 SPECTRO XEPOS — 19.01.2017
How to measure large samples
In order to measure large samples, the sample tray and, if necessary, the sample
tray support must be removed.
To do this, proceed with the following steps:
1. Remove the sample tray as described in Chapter "How to change/remove the
sample tray" on page 38.
2. Use an Allen key to loosen the
tray screw (1).
3. Remove the sample tray
support.
Fig. 12
4. If possible, use the single
sample holder (1) that is
included with the delivery.
Fig. 13
Three single sample holders are included with each delivery. Additional holders
can be ordered from our SPECTRO Shop. The part number can be found on page
55.
The installation of the sample tray and the sample tray support takes place in
reverse order. During the installation of the sample tray support, tighten the tray
screw until the sample tray support can be rotated.
1
1
