ST STM32H7B3I-EVAL User Manual

Table 69. Daughterboard extension connector CN5 right even pins
Pin number Pin name Pin function How to disconnect
2 PI13 RGB_LCD_VSYNC R214
4 PC14 OSC32_IN R23
6
PC13
(1)
KEY_TAMP_1/WKUP2 R16
8 PI8 INT_MFX_IRQ_OUT R168
12
PA6
(1)
DCMI_PIXCLK || I2S6_EXT_SD_BKUP || MOTOR_TIM1_BKIN JP6
14
PB4
(1)
I2S6_EXT_SD || NJTRST JP8
16 PB3 JTDO/TRACESWO R32
18 PK7 RGB_LCD_DE R248
20 PK4 RGB_LCD_B5 R254
22 PG13 LED1 R178
24
PJ12
(1)
RGB_LCD_B0 || TRGOUT R259
26 PJ13 RGB_LCD_B1 R264
28 PJ14 RGB_LCD_B2 R269
32 PD3 DCMI_D5 R48
34 PC11 SDIO1_D3 R51
36 PA15 JTDI R53
38 PA13 JTMS-SWDIO R57
40
PA10
(1)
USB_FS_ID || MOTOR_TIM1_CH3 R58
42
PA9
(1)
USB_FS_VBUS || MOTOR_TIM1_CH2 R60
44
PC8
(1)
SDIO1_D0 || SRAM_BKUP_NE3 JP12
46 PG7 SAI1_MCLK_A JP14
52 PJ11 RGB_LCD_G4 R302
54 PK0 RGB_LCD_G5 R305
56 PJ10 RGB_LCD_G3 R312
58 PJ6 RGB_LCD_R7 R317
1. Pins shared between different functions and requiring hardware configuration (Such as jumper and soldered bridges)
UM2662
Daughterboard extension connectors CN5 and CN6
UM2662 - Rev 1
page 72/95
