Standard Imaging QA BEAMCHECKER PLUS User Manual

QA BEAMCHECKER™ PLUS 83
Dimensions (Precision Leveling Platform):
Triangle Side Length:
Height:
38 cm (14.96 in)
6.5 cm (2.56 in)
Weight:
QA BeamChecker Plus:
Power/Data Cradle:
Gantry Mount:
Precision Leveling Platform:
5.0 kg (11 lbs)
1.8 kg (4 lbs)
5.3 kg (11.68 lbs)
1.25 kg (2.75 lbs)
Mode of Operation:
Continuous
Power Requirements:
Battery:
Battery Recharge Time:
Charger Input:
1.2 Ah SLA, 4 hours of continuous use.
Approximately 8 hours from full discharge.
90 – 240 VAC, 50-60 Hz, EN/IEC 60601-1 approved power
supply, GlobTek
®
, Inc. model GTM96180-1811-2.0-T3
The use of any other power supply and using alternates other than the
UL/CSA recognized power cord can degrade minimum safety. The
proper replacements from Standard Imaging, Inc. are required for
compliance with the requirements of IEC 60601-1.
Product Standards:
IEC 60601-1
1
, IEC 60601-1-2
1
,
Patents:
US Patent Numbers 7,189,975 and 7,470,912
PC Hardware Requirement:
Available COM port within range of COM1 through COM8;
RS-232 Default: Uni-directional 19,200 baud, 8 data bits,
no parity, 1 stop bit
Software/Computer Requirements:
Operating System:
Processor:
Memory:
Hard Drive:
Screen Resolution:
Optical Drive:
Connectivity:
Windows 10 Professional, 64 bit recommended
Dual Core, 1 GHz; Quad Core, 2 GHz Recommended
32-bit OS: 2 GB, 4 GB Recommended 64-bit OS: 4 GB, 8 GB
Recommended
32 GB or greater, 1 GB free space for initial software setup.
25% free space recommended.
1024 x 768 or greater
Compact Disc (CD) or Digital Versatile Disc (DVD)
9 pin RS-232 serial port and IPv4 LAN, 100 Mbit/s or greater

Standard Imaging QA BEAMCHECKER PLUS Specifications

General

Software	QA Beamchecker Plus Software
Interface	USB
Power	USB powered
Angular Range	0° - 360°
Field Size Range	Up to 40 x 40 cm
Power Supply	USB
