NOTE: If using a TomoTherapy System or Dynamic 5 Channel room, the QA BeamChecker Plus
must be flipped to the Photon side to ensure correct labeling of the left and right chambers.
7. Select the Physics tab at the bottom of the screen to view the Physics mode interface.
9.2 Working with Physics Mode
1. If a Static 5 Channel room is selected, first select Photons or Electrons depending on which
side of the device is flipped up. If a TomoTherapy System room is chosen, select Static or
Dynamic. If a Dynamic 5 Channel room is used, no selection is required.
2. Click the Start button to begin measurement.
3. Elapsed Time is shown along with Rate and Charge measurements displayed on the
graphical representation of the QA BeamChecker Plus chamber layout. The measurement will
continue until the Stop button is clicked.
