QA BEAMCHECKER™ PLUS 44
NOTE: When downloading data, all data from all rooms is transferred to the Communication
Software database.
NOTE: It is not necessary to download acquired data from the QA BeamChecker Plus after
every Wire-Free session. The QA BeamChecker Plus internal memory will hold up to 512
measurements before the data will need to be transferred to the software database.
8.2 Selectively Viewing Data
Data acquired in Wire-Free or Real-Time Operation modes can be viewed by energy when
browsing data for a Static 5 Channel room, or by plan for a Dynamic 5 Channel or
TomoTherapy room. From the Energy or View panel, use the pull down menu to select an
acquired energy or test from the list. The energy and type will appear along with the
parameters that were specified at the time of baseline creation.
Using the Chart View
The Chart View shows measurements points on a graph, with the x-axis representing the date
and the y-axis representing the deviation from the baseline. Points on graph appear in one of
three regions:
Green Below action level 1
Yellow At or above action level 1, but below action level 2
Red At or above action level 2
