9.3.2 Installing the cover
1. Position the cover on the casing so that the two guide lugs on the cover fit into the guide
slots in the casing.
2. Slide the cover onto the casing until it audibly latches into place.
9.4 Installing the device
1. Select the mounting location under consideration of the previously mentioned safety require-
ments.
2. Remove both controller covers.
3. Position the controller level on the mounting surface and mark the mounting holes through
the fastening openings .
4. Remove the controller and drill the mounting holes.
5. Use 4 suitable screws (max. M5) to fasten the controller to the mounting surface.
6. Install the covers.
ATTENTION!
Danger of damage to the controller and reduction of power. Observe the following safety
requirements during installation:
– The mounting location and immediate environment are permanently fixed, vertical, flat,
non-inflammable and not subject to constant vibration.
– A free space of at least 60 mm must be present on all sides of the controller. The required
free space relates to the controller without covers; see in Fig. 10.
– The controller must be easily accessible and the display easily readable.
– The controller is mounted as close as possible to the battery; the prescribed minimum
safety clearance of 0.5 m between the controller and battery is adhered to.
– The controller must not be located
– outdoors or in a location subject to rain or splashing water,
– in dusty environments,
– in areas with active animal husbandry,
– in direct sunlight.
– The battery cable is no longer than 2 m (recommended), to keep cable losses and compen-
sating voltage as low as possible.
– Do not drill through the fastening openings (Fig. 10).
