Commissioning the microSD card
1. Insert a formatted microSD card.
2. Configure the data logging function and save/load the parameters as described in section
14.3.10 'SD card'.
CAUTION!
Never forcibly insert or remove the microSD card. This can damage the card holder and/or the
microSD card.
NOTICE
– A microSD card is not included in the scope of delivery for the device.
– microSD and microSDHC cards with a capacity of up to 8 GB can be used.
– The microSD card must be formatted with a FAT16 or FAT32 file system.
– Using the microSD card, the data of the device as well as of connected StecaLink slave
devices can be recorded.
– Using the microSD card, setting parameters of the device can be saved and read in.
– Take care to observe the correct insertion direction, as shown on the microSD card and the
device.
– Carefully and gently push the microSD card into the opening in the device casing until it
latches into place.
– Remove the microSD card by pushing it towards the device until it unlatches, then let go of
the card and, finally, pull the card out (Push-Pull connector).
– Data recording onto the SD card is deactivated at the factory.
