Event message
Cause Remedy 1) 2)
No. Text
09 Overload Attention
Q Danger of destroying the converter through overloading.
Loads that consume more current than can be supplied
by the controller must be directly connected to the bat-
tery.
Q Always directly connect inverters to the battery!
Note
If the event message occurs again when the load is connected
then too many loads are connected to the controller. If the
event message occurs again a certain time after the load is
connected then individual loads are probably generating
short-term peak currents, e.g. heavy-duty electric motors.
X
The maximum
permissible load
current has been
exceeded and
the controller
has switched off
the load output.
1. Switch off the loads to reduce the load
current.
2. Switch on the loads individually.
3. Contact your dealer if this event mes-
sage occurs again after all loads have
been switched on. Specify whether the
event message occurs immediately or
a certain time after switching on the
loads.
10 PV current
too high
The maximum
permissible
module current
has been
exceeded
because the solar
module is over-
dimensioned.
Contact your dealer. X
11 Load short
circuit
A short circuit
exists at the load
output.
1. Switch off all loads.
2. Switch off the load output, see section
13.5.
3. Correct the short circuit (wiring, load).
4. Switch on the load.
5. Switch on the load output.
X
13 Battery not
connected
The solar module
is supplying
voltage but the
battery is not
recognised.
Take the following measures if appro-
priate
Q Connect the battery.
Q Check the external battery fuse and
replace if necessary.
Q Check the battery cable connections.
Q Check the battery cable for breakage.
X
