Signal / information Value Units Action
UART Data info 17 Error Error state: 0-No errors, 1-Information,
2-Warning, 3-Error
UART Data info 18 Charging mode Charge mode identifier, F, B, L, S
UART Data info 19 Load output Switching state of load output
0-OFF, 1-ON
UART Data info 20 AUX 1 Switching state of AUX 1 relay
0-OFF, 1-ON
UART Data info 21 AUX 2 Switching state of AUX 2 relay
0-OFF, 1-ON
UART Data info 22 Energy input 24 h Ah Ah meter of the energy input members total
during the period from 00:00 to 23:59
UART Data info 23 Energy input/total Ah Ah meter of the energy input members total
since initial commissioning
UART Data info 24 Energy output
24 h
Ah Ah meter of the energy output members total
during the period from 00:00 to 23:59
UART Data info 25 Energy output/
total
Ah Ah meter of the energy output members total
since initial commissioning
UART Data info 26 Derating Ah 0- Derating not active, 1- Derating active
UART Data info 27 Checksum A CRC16 checksum is generated. Name: ‘CRC-
16-CCITT/openUART’ Width: 16 Direction: right
shift Polynomial: 0x8408 CCITT reversed, 2 bytes
long, stored as high-byte, low-byte. The CRC is
calculated with semicolons and without CR+LF.
UART Data info 28 End of data CR + LF
