STEP ET Series - P22 Group Auxiliary Parameters

Chapter 7 Parameter Explanation
ET/EP/EH Series Intelligent Flexible Driver Manual
- 99 -
Function code
Name
Setting range
Factory setting
P21.06
Stator resistance of motor 2 (Ω)
0.000~65.000
0.100
P21.07
Rotor resistance of motor 2 (Ω)
0.000~65.000
0
P21.08
Stator inductance of motor 2 (H)
0.0000~6.5000
0
P21.09
Rotor inductance of motor 2 (H)
0.0000~6.5000
0
P21.10
Mutual inductance (H)
0.0000~6.5000
0
Descriptions of the parameters P21.06 - P21.10 of motor 2 are the same as that of motor 1.
Function code
Name
Setting range
Factory setting
P21.11
PM1 stator resistance (ohm)
0.000~65.000
0.100
P21.12
PM1 motor shaft D inductance
0.000~6553.5
0
P21.13
PM1 motor shaft Q inductance
0.000~6553.5
0
P21.14
PM1 back electromotive force
coefficient (V)
0.0~690.0
0
P21.11 - P21.14 are parameter of synchronous motor.
P21.15~P21.20 are the results of asynchronous motor auto-tuning, which are used for display only.
Function code
Name
Setting range
Factory setting
P21.21
Inertia coefficient
0.000~65.000
0.200
Appropriately adjust this value according to the actual system inertia.
Function code
Name
Setting range
Factory setting
P21.22
Parameter deviation
compensation
0.0~100.0
0.0
Generally not used.
7.4.3 P22 group Auxiliary parameters
Function
code
Function code name
Factory
default
Setting
range
Unit
Attrib
ute
Option description
P22.01
Encoder 1 type
0
0~3
/
×
0: Incremental; 1: SinCos; 2:
EnDat(backup); 3: Rezav
P22.02
Encoder 1 pulse count
1024
100~16000
ppr
×
Encoder pulse number
P22.03
Encoder frequency
dividing coefficient
0
0~7
/
×
Encoder frequency dividing
coefficient
P22.04
Encoder 1 position
angle
0.0
0.0~360.0
degree
*
Encoder position angle
P22.05
Encoder feedback
speed filtering time
constant
10
0~1000
ms
×
P22.06
Encoder 1 direction
1
1~1
/
×
1: Positive phase sequence
P22.07
SinCos encoder
subdivision coefficient
11
2~16
/
×
7—128;9-512;11-2048
P22.08
Rezav encoder 1 pole
count
2
2~128
P
×
This group of parameters selects encoder 1 type, pulses per revolution, etc, division coefficient, etc.
The Position angle is from reading in self-learning, unable to be set. The filtering time shall be
adjusted within a controllable range. P22.06 or hardware line changing shall be selected for encoder
according to actual situation.
P22.01 setting encoder type, 0: Incremental encoder; 1: SinCos encoder; 2: Spare; 3: Rezav encoder.
P22.02 setting the encoder pulse count.
