STEP ET Series - P31 Group Digital Input

Chapter 7 Parameter Explanation
ET/EP/EH Series Intelligent Flexible Driver Manual
- 105 -
7.5.2 P31 group Digital input
Function code
Name
Setting range
Factory setting
P31.00
Output K1 function definition
0~199
2
P31.01
Output K2 function definition
0~199
25
P31.02
Output Y0 function definition
0~199
0
P31.03
Output Y1 function definition
0~199
0
Y0 - Y1 terminal outputs can be defined as multi-functional switching outputs or as high-speed pulse
outputs (function 19, 20), and K1 – K2 relay outputs can also be defined as multi-functional outputs,
but not as pulse outputs.
Function definition table of multifunction switch output
Functio
n
settings
Meaning
Function
settings
Meaning
0
No function
1
Normal power-on self-inspection
2
Fault output
3
Running
4
Frequency arrival output
5
Frequency consistency output
6
Zero speed signal output
7
Normal bus voltage
8
It exceeds 5% of rated current
during running and 10% of rated
current when stop running
9
In tuning
10
Frequency detection 1
11
Frequency detection 2
12
Predicting fault output
13
Auto-tuning request output
14
Zero servo torque direction
15
Zero current detection output
16
Power generation/electric status
17
Output contactor control
18
Brake contactor control
19
Pulse output 0
20
Pulse output 1
21
Radiator overheat alarm
22
Motor overheat alarm
23
Motor option output
24
Encoder option output
25
Brake output
26
Cumulative runtime arrival
27
Single runtime arrival
28
Output X1
29
Output X2
30
Undervoltage blocking is stopping
31
Fan control
32
Analog disconnection
33
Motor PTC overheating
34
Reverse running
35
Sleep
36
Alarm output
37
Amplitude and phase locking
completed
38
Frequency detection 3
39
Frequency detection 4
Settings of six parameters P31.00 - P31.05 defines the functions of six output ports from K1 – K2
and Y0 - Y1. The range of setting values and the function of the corresponding output port when
setting each value are as follows.
0: No function
1 or 101: Inverter running preparation completed (RDY)
1: The self-test of the inverter is normal without fault, and the corresponding output point is
connected, otherwise it will be disconnected;
101: The self-test of the inverter is normal without fault, and the corresponding output point is
disconnected, otherwise it will be connected.
2 or 102:Inverter fault
