Register address
Description
bit7
Unused
bit15~8
Unused
# Actual value of terminal output = Modbus setting value | internal output value of
functional terminal
0008H
Reserved (Modbus broadcast data validity)
bit0
1: Terminal DI0 Modbus broadcast preset
valid
0: invalid
bit1
1: Terminal DI1 Modbus broadcast preset
valid
0: invalid
bit2
1: Terminal DI2 Modbus broadcast preset
valid
0: invalid
bit3
1: Terminal DI3 Modbus broadcast preset
valid
0: invalid
bit4
1: Terminal DI4 Modbus broadcast preset
valid
0: invalid
bit5
1: Terminal DI5 Modbus broadcast preset
valid
0: invalid
bit6
1: Terminal DI6 Modbus broadcast preset
valid
0: invalid
bit7
1: Terminal DI7 Modbus broadcast preset
valid
0: invalid
bit8
Unused
bit9
Unused
bit10
1: Target frequency broadcast preset value
valid
0: invalid
bit11
1: Current frequency broadcast preset value
valid
0: invalid
bit12
1: valid reference value for running command (forward rotation, reverse
rotation and start-stop command) broadcast
bit15~13
Unused
0009H
Reserved (reference value for target frequency broadcast)
000AH
Reserved (reference value for current frequency broadcast)
000BH
Reserved (reference value for operation signal broadcast)
bit0
Reference value for Modbus broadcast of terminal DI0 # (the corresponding
specific function is set by parameters)
bit1
Reference value for Modbus broadcast of terminal DI1 # (the corresponding
specific function is set by parameters)
bit2
Reference value for Modbus broadcast of terminal DI2 # (the corresponding
specific function is set by parameters)
bit3
Reference value for Modbus broadcast of terminal DI3 # (the corresponding
specific function is set by parameters)
bit4
Reference value for Modbus broadcast of terminal DI4 # (the corresponding
specific function is set by parameters)
bit5
Reference value for Modbus broadcast of terminal DI5 # (the corresponding
specific function is set by parameters)
bit6
Reference value for Modbus broadcast of terminal DI6 # (the corresponding
specific function is set by parameters)
bit7
Reference value for Modbus broadcast of terminal DI7 # (the corresponding
specific function is set by parameters)
bit8
Unused
bit9
Unused
bit10
1: forward rotation 0: invalid
bit11
1: reverse rotation 0: invalid
bit12
1: running 0: stop
bit13
1: external fault
bit14
1: reset fault instruction
bit15
Unused
# Adopted value for function input terminal = (Modbus broadcast value & validity of
reference value for broadcast) | Actual input value of function terminal
000CH~0018H
Reserved (broadcast data)
0019H
Virtual input terminal
Bit0: virtual terminal X0
Bit1: virtual terminal X1
