Parameter set to 10 current output torque of the inverter, signed, standard value for rated motor
torque, 999 means 99.9%, -1000 means -100.0%
Parameter set to 11-12 standby
Parameter set to 13 reference target frequency of the inverter, unsigned, 5000 means 50.00Hz
Parameter set to 14 current operating frequency of the inverter, signed, 5000 means 50.00Hz,
-5000 means -50.00Hz
Parameter set to 15 feedback frequency of the inverter, signed, 5000 means 50.00Hz, -5000 means
-50.00Hz
Parameter set to 16 feedback velocity of the inverter, signed, 1000 means 100.0rpm, -1000 means
-100.0rpm
Parameter set to 17 standby
Parameter set to 18 effective output voltage of the inverter, unsigned, 380 means 380V
Parameter set to 19 effective output current of the inverter, unsigned, 100 means 10.0A
Parameter set to 20 active output power of the inverter, unsigned, 1000 means 100.0% of the rated
motor power
Parameter set to 21-22 standby
Parameter set to 23 bus voltage of the inverter, unsigned, 537 means 537V
Parameter set to 24-25 standby
Parameter set to 29 output terminal status of the inverter, 1: ON 0: OFF
Parameter set to 30 standby
Parameter set to 31 input terminal status of the inverter, 1: ON 0: OFF
Parameter set to 32-33 standby
Parameter set to 34 analog input channel 0, 10000 means 10.000V
Parameter set to 35 analog input channel 1, 10000 means 10.000V
Parameter set to 36-39 standby
Parameter set to 40 number of the most recent fault 0~63
Parameter set to 41-42 standby
Parameter set to 43 radiator temperature, 60 means 60 degrees Celsius
Parameter set to 44 encoder count 0~65535
Parameter set to 45-59 standby
