5-13
Operating Instructions Operator Manual 10083002
• Range of upward motion for spring arm can be adjusted to 20°,
30°, or 40° above horizontal, to expand storage/parking options
when monitors are not in use.
• If weight or range of motion for flat panel monitor mount system is
changed in any way, refer to I
NSTALLATION INSTRUCTIONS,
10043126 for procedures to help ensure proper balancing and
motion.
Figure 5-10. HarmonyAIR Surgical Lighting System M Series Monitor Arms, Part 1
Dual Flat Panel Monitor
Single Flat Panel Monitor
