Steris Harmony LED Wall Control Unit

To Next Page

To Previous Page

5-14

10083002 Operator Manual Operating Instructions

Figure 5-11. HarmonyAIR Surgical Lighting System M Series Monitor Arms, Part 2

320°

10° UP

10° DN

320°

15° UP

90° DN

15° UP

90° DN

10° UP

10° DN

10° UP

10° DN

Finished Ceiling

10° Clockwise

10° Counterclockwise

10° Clockwise

10° Counterclockwise

Finished Floor
