Why is there no mains power to my stertil ST1175 Lifting Systems?
The Stertil Lifting Systems might not be receiving mains power due to several reasons: * There is no mains power. * The mains fuse has blown and needs replacing. * The mains switch is turned OFF and needs to be switched ON. * The LEDs are defective.
What to do if Stertil column lift does not rise?
If the Stertil column lift isn't rising, here are a few potential causes and solutions: * **No mains/control power:** Check the power supply. * **Low oil level:** Top up the oil. * **Air in the hydraulic pump:** Select [SINGLE] operation and press the [UP] button (max. 1 minute). * **Incorrectly adjusted pressure relief valve:** Contact technical services. * **Inadequate pump capacity:** Replace the pump. * **Thermal relay interruption:** Reset the thermal relay. * **Exceeded height difference:** Set the main switch OFF and ON, then press the [SELECT] button twice. * **Incorrectly connected phases:** Exchange two phases in the plug or main box.
What to do if my Stertil column lift will not lower?
If your Stertil column lift won't lower, consider these possibilities: * **No mains/control power:** Verify the power supply. * **Pawl not retracting:** Raise the lift slightly (approx. 1 3/8") before lowering. * **Electrically operated lowering valve issue:** The lowering valve might not be opening due to no voltage or a fault. * **Maximum elevation difference exceeded:** Press [UP] to level the difference. If lifting isn't needed, press [SELECT] three times to lower with a persistent difference of 1 3/16". * **Maximum height difference exceeded:** Set the main switch OFF and ON, then press the [SELECT] button once. * **Highest position near locking position:** The height needs to be reset.
Why is there no control voltage in my stertil ST1175 Lifting Systems?
If there is no control voltage in your Stertil Lifting Systems, here are some things to check: * The lifting system may not be set up properly, so follow the normal operation procedures. * A fuse may have been tripped; check and replace the F2 and F3 fuses in the control box if needed. * The mains switch is OFF; set it to ON. * There may be a broken cable or loose connector; check the cable and connector. * The emergency stop button may not have been unlocked; unlock the button, set the main switch to OFF and ON, and press the [SELECT] button once. * The thermal relay in the main box may have been deactivated; reset the thermal relay.
Why does the Stertil column lift lowers of its own accord?
The Stertil column lift might be lowering on its own due to: * A damaged cylinder seal causing continuous oil leakage. In this case the cuff or the cylinder should be replaced. * Leaks in the oil line couplings. Try tightening the couplings or union nuts. * A dirty or damaged non-return valve. The non-return valve should be cleaned or replaced. * A contaminated or damaged lowering correction valve. The valve should be cleaned or replaced.
What to do if the Stertil column lift is not raising far enough?
If the Stertil column lift isn't raising far enough, consider these potential causes: * The oil level in the tank is too low. Top up with oil. * The pump is drawing air. Tighten or crimp the suction filter attachment. * The steel plug has not been replaced by the air bleed cap. Fit the air bleed cap. * The air bleed cap is blocked. Clean the air bleed cap.
Why do Stertil column lifts not go up at the same speed?
The Stertil column lifts may not be ascending at the same speed due to the control system not working correctly. To resolve this, use the S1 (UP) and S2 (DOWN) switches in the control box to lift and lower without the safety measures in place. Operate the switches until the column lifts are level.
What does it mean if the red (FAULT) push button indicator flashes when the [UP] button is pressed on stertil ST1175?
If the red (FAULT) push button indicator flashes when the [UP] button is pressed on your Stertil Lifting Systems, it means the column lift has reached its highest point. Pressing the [DOWN] button will allow the column lift to operate normally again.
Details risks associated with electrical systems, moving parts, and working at heights.
Provides overarching safety guidelines, operator responsibilities, and adherence to procedures.
Describes the lift's built-in safety systems and the critical emergency stop function.
Outlines energy isolation procedures and addresses disposal and REACH compliance.
Lists key performance data, dimensions, power requirements, and maximum lifting capacity.
Instructions for standard lift operations, slow lowering, and engaging safety locks.
Highlights safety precautions during maintenance and outlines daily, monthly, annual schedules.
Procedures for checking safety features and configuring programmable settings.
Guidelines for repairs, required knowledge, parts ordering, and mechanism adjustments.
Comprehensive list of error codes, faults, their causes, and recommended solutions.
Troubleshooting for power issues, voltage faults, indicator lights, and emergency lowering.
General| Brand | stertil |
|---|---|
| Model | ST1175 |
| Category | Lifting Systems |
| Language | English |
