Operation & Service Manual (VA) 34 ST1175
Length of cable between the column lifts
Maximum distance between the column lifts
Maximum floor loading on front support plates
4.2 Lifting capacity
See Technical specifications for specifications of the maximum lifting capacity. The
overpressure safeguard in the hydraulic unit has been preset so that the lift can
never raise more than the specified weight +10%.
4.3 Lifting system
This mobile column lift is an electrically driven hydraulic column lift for lifting heavy
vehicles. A minimum of two column lifts is needed to lift a vehicle. The number of
column lifts required depends on the weight of the vehicle and the number of
axles. Usually, four column lifts are used; one master column and three slave
columns.
