Operation & Service Manual (VA) 49 ST1175
[UNLOCK] (button 6) and [DOWN] (button 4)
all column lifts are lowered.
[SELECT] (button 5) and [PAIR] (light 11) and [UP] (button 3)
one axle rises (2 column lifts).
[SELECT] (button 5) and [PAIR] (light 11) and [DOWN] (button 4)
one axle is lowered (2 column lifts).
[SELECT] (button 5) and [SINGLE] (light 10) and [UP] (button 3)
one column lift is raised
[SELECT] (button 5) and [SINGLE] (light 10) and [DOWN] (button 4)
one column lift is lowered.
[TURTLE] (icon) and [DOWN] (button 4)
columns are lowered slowly.
This works for [ALL], [PAIR] and [SINGLE].
Lower the column lifts into the safety locks and set the mains switch to 0 (OFF)
once the desired height has been reached.
When using just one or two column lifts (when operating in pairs), make certain
that there is no possible danger of instability; see also section Safety when
hoisting. If in doubt, ask your supervisor.
Unsafe lifting can lead to serious injuries and damage to the lifting system and the
vehicles.
6.7.3 Unblocking in case of emergency
In emergency situations, it is possible to lower the column lifts manually.
Manual lowering may only be carried out by an authorized technician.
