Operation & Service Manual (VA) 26 ST1175
The next table gives an overview of the various safety signs used on or in the
vehicle lift. For each sign the locations where they are fitted are indicated.
Pictogram
Description
Location
Capacity sticker
(example).
The value stated on this
sticker gives the
maximum lifting
capacity of the column.
At the left or right
side of the
column.
Operation sticker
(example).
On this sticker the a
short description of the
operation of the column
is given.
At the operating
side of the
column, under the
control box.
Safety instruction
labels.
At the front side
above the control
box.
