stertil ST1175 - Page 5

Operation & Service Manual (VA) 5 ST1175
7.12 Replacement parts 66
8 Troubleshooting 67
8.1 General 67
8.2 Error messages 67
8.3 Error codes 69
8.4 Faults 72
8.4.1 The column lift does not rise 73
8.4.2 The column lift will not lower 74
8.4.3 The column lift lowers of its own accord 75
8.4.4 The column lift is not raising far enough 75
8.4.5 The column lifts do not go up at the same speed 75
8.4.6 No mains power 76
8.4.7 No control voltage 76
8.4.8 The red (FAULT) push button indicator flashes when the [UP] button is pressed 77
8.5 Emergency lowering facility 77
8.6 Technical support 77
9 Options 78
9.1 Special adapters 78
10 List of Parts 79
10.1 Main components 80
10.2 Hydraulic unit 84
10.3 Hydraulic cylinder 86
10.4 Control box (primary) 88
10.5 Control box (secondary) 90
10.6 Connection cable 92
10.7 Pallet jack mechanism 93
10.8 Label locations 95
11 List of Parts - Variants and Options 97
11.1 Special adapters 98
12 Appendices 99
12.1 Control box sticker 99
12.2 Electrical diagram for the primary control box 100
12.3 Electrical diagram for the secondary control box 101
12.4 Hydraulics diagram 102
12.5 Dimensional drawing 103
12.6 Inspection checklist 104
Index 105
