Operation & Service Manual (VA) 89 ST1175
Pos
Qty
Part No.
Description
Remarks
32707950
Control box 1x208V, 60Hz
32707200
Control box 3x220V, 60Hz
32707100
Control box 3x460V, 60Hz
32707920
Control box 3x575V, 60Hz
1
1
32707125
Box
2
1
69900135
PCB
3
1
69500007
Trafo
4
1
69152006
Motor relay
5
1
32707050
Foil covered switch panel
6
1
69154001
Main safety relay
7
2
69156009
Safety relays
9
1
69141050
Main switch
10
2
69090114
Connector
11
1
69090112
Connector internals (male)
12
1
69090111
Connector internals (female)
14
1
Cable gland M32x1.5 23254uz13 red
16
1
Cable gland M20x1.5 22052um2x6
17
1
Cable gland M25x1.5 22553um2x8
21
1
Cable gland M20x1.5 22052u11 green
23
2
69206010
Fuse 125 mAT 250V (F3)
24
2
69206012
Fuse 3,15 AT 24V (F2)
26
1
69202008
Acoustical alarm
27
1
69153002
Therm. relay 3x575V, 60Hz 7-10A
27
1
69153003
Therm. relay 3x220V, 60Hz 20-25A
27
1
69153004
Therm. relay 1x208V / 3x460V, 60Hz 11-16A
32
1
Cable power supply
34
1
Motor cable
35
1
Cable lowering valve
36
1
Cable correction valve
37
1
Cable unlocking solenoid
38
1
Cable potentiometer
