Operation & Service Manual (VA) 91 ST1175
Pos
Qty
Part No.
Description
Remarks
32707300
Control box 3x220/460/575V, 60Hz
32707970
Control box 1x208V, 60Hz
1
1
32707125
Box
2
1
69900135
PCB
3
1
69500007
Trafo
4
1
69152006
Motor relay
5
1
32707050
Foil covered switch panel
6
1
69141061
Emergency stop
7
2
69141041
NC contactor
10
2
69090114
Connector
11
1
69090112
Connector internals (male)
12
1
69090111
Connector internals (female)
16
1
Cable gland M20x1.5 22052um2x6
17
1
Cable gland M25x1.5 22553um2x8
21
1
Cable gland M20x1.5 22052u11
green
23
2
69206010
Fuse 125 mAT 250V (F3)
24
2
69206012
Fuse 3,15 AT 24V (F2)
26
1
69202008
Acoustical alarm
34
1
Motor cable
35
1
Cable lowering valve
36
1
Cable correction valve
37
1
Cable unlocking solenoid
38
1
Cable potentiometer
