Control unit with internal switch mode power supply (optional):
Type
LINAK CB06 OpenBus
®
Input voltage
AC 120 – 240V ± 10 %, 50/60 Hz
Max. current input
AC 2.0 A
Internal device fuse
2-fold electronic, automatic-resetting overload
protection;
Duty cycle
Intermittent duty: 2 min ON / 18 min OFF
Protection category
IP X4
Classification
Protection Class II, Type B, MPG classification Class I,
not for use in explosive atmospheres
External switching power supply:
Type
LINAK SMPS 20
Input voltage
AC 230 V, 50/60 Hz, -15% - +10%
Mains plug of switch mode
power supply
2-pole – Europlug (EN50075)
Current input
AC max. 2.5 A
Output voltage
DC 34 V
Output current,
electronically limited,
max. 10 A
Activated via remote signal
Duty cycle
Intermittent duty: 2 min ON / 18 min OFF
Protection category
IP X4
Classification
Protection Class II, Type B, MPG classification
Class I,
not for use in explosive atmospheres
Output cable
Approx. 2.5 m, with special plug, 4-pole
Handset:
Type
Linak HL7xx -OpenBus®
Protection
category
IP X4
Additional handset for Trendelenburg/reverse-Trendelenburg position
(optional)
Type
Linak HL7xx -OpenBus®
Protection
category
IP X4
