Instruction Manual for Libra Care Bed
Page 79
4.6 INSERTING THE MATTRESS
Place a suitable mattress on top of the mattress base. Please comply with the
permissible dimensions and characteristics of the mattress (for mattress dimensions,
see chapters 4.5 and 9.1).
Risk of injury
Failure to heed this warning may risk injury to patients from entrapment or
suffocation between the displaced mattress and the raised safety sides.
• Only use mattresses with the specified dimensions and
characteristics that are approved by the manufacturer for use with
this bed.
• Always lay the mattress 1 between the 4 lateral mattress retainer
bars 2 of the mattress base. This prevents the mattress from
moving outwards at the sides of the bed.
• Please also note any other possible position markings on the
mattress (such as “Oben/Top”, “Kopf/Head”).
• Always place the mattress onto the mattress base in the way
described below.
Top view
(shown
schematically):
Mattress base
with properly
inserted
mattress
Detail (shown schematically): CORRECT:
Mattress lies between the mattress retainer bars
Detail (shown schematically): INCORRECT: Mattress
lies outside/above the mattress retainer bars
Mattress retainer bars are supplied as fixed-position or fold down bars, depending on
the features of the bed.
