4.5.5 Split safety sides *
Libra can be fitted with optional split safety sides “Vario Safe system”.
Risk of injury due to incorrect installation or storage of split
safety sides, headboards, footboards or side panels with the
“Vario Safe” system!
Failure to observe these instructions can result in insecure
fastening and/or material damage and can thus put the resident at
risk of falling or becoming trapped.
• Please carefully follow the assembly steps described below.
• After assembly, carry out the mandatory checks to make sure
that the fixings are secure.
• To ensure that the plastic locking levers of the “Vario Safe”
system function properly, do not allow them to fall or suffer
severe knocks during disassembly or storage.
• Never use “Vario Safe” systems that are damaged.
4.5.5.1 Installation
The split safety side consists of four parts. These simply click onto the long sides of
the bed to attach. The safety sides are available in two sizes: 2 x long (110 cm) and 2
x short (90 cm). One short and one long safety side are mounted on each side of the
bed.
Start with the long safety side, at the head end on the left-hand side:
First swivel the locking levers of the safety side 2 (left and right side)
downwards.
To do this, pull the orange safety lock 1 outwards with your finger and hold it in
this position while swivelling the locking lever downwards.
