Stiegelmeyer Libra - Full-Length Safety Sides (Standard)

Instruction Manual for Libra Care Bed
Page 52
4.5.1 Full-length safety sides (standard)
4.5.1.1 Raising
• At the headboard and
footboard, pull the upper bar of
the safety side upwards as far
as it will go, first at one end and
then at the other. The lower bar
follows.
• Check that the safety side is
securely engaged by pressing
on the upper bar.
• Repeat the process on the
other safety side.
4.5.1.2 Lowering
• Before lowering the safety side, make sure that the resident’s limbs
are not located within the area of movement of the bars. This
prevents the resident from being crushed or sustaining other injuries.
1. Lift the upper bar 1 slightly with one
hand and hold it in place.
2. Press the release button 2
and lower the safety
side 1 carefully.
Do not let it drop!
• Repeat this procedure at the other sides.
2
1
