Instruction Manual for Libra Care Bed
Page 2
Libra care bed
Similar to illustration!
In this instruction manual, numbers and letters that appear in round brackets ()
and bold type refer to the care bed’s operating devices as shown in this and the
following images.
Item
Description
1
Footboard
2
Full-length safety side bars (standard)
3
Removable centre support (optional)
4
Handset
5
Headboard
6
Combined safety side with bars (optional)
7
Mattress retainer bar
8
Side panel
9
Holder for centre support (optional)
10
Individual axle braking (standard)
Central locking (optional) – only operated at foot end
1
2
3
4
5
5
6
8
10
10
9
7
