Instruction Manual for Libra Care Bed
Page 42
4.4.8.1 Attachment
1.
Standing behind the
headboard/footboard, firmly grip the
uppermost corners of the
headboard/footboard with both hands
2.
Insert the locking hooks 1 of the
adapters into the slits of the cross
tube 2 as far as they will go and
make sure the headboard/footboard is
fitted securely
3.
Swivel the locking levers 3 (left and
right side) upwards and press until they
audibly click into place
4.
Check that the headboard or
footboard is firmly in place by jiggling
the top edge of the head and
footboards to and fro
1
1 2
1
3
