Instruction Manual for Libra Care Bed
Page 69
4.5.5.3 Sticker split safety sides
Risk of injury through incorrect installation of split safety sides!
Non-observance can lead to entrapment of body parts.
Please note: There is a sticker in the middle of the long side of the
mattress base frame (see illustration). This sticker warns you not to
attach two 90 cm long split safety sides to one side of the bed. Doing so
creates a gap between the two safety sides, which leads to a risk of
entrapment of limbs.
Only install the permitted sizes of the split safety side per bed side
(more on this on the next page)
Observe the following table when installing split safety sides.
Assembly on beds without a bed
extension
Assembly on beds with a
bed extension (approx. 20
cm)
Per bed
side
1x size 110 cm (head end/foot end)
1x size 90 cm (head end/foot end)
2x size 110 cm
For more details please refer to the next page ...
